Editor’s note: Those of you in the space community know that NASA Science is facing an immense budget cut. Dozens of missions have been cancelled and many missions that are still returning valuable data are being shut off – in many cases to save a few million dollars – a tiny fraction of what it took to mount the missions in the first place. This data will be lost. In the case of New Horizons, currently traversing the outer solar system, NASA is going to forfeit a third interstellar mission (after the twin Voyagers). This latest interstellar mission would be done with a healthy spacecraft outfitted with 21st century instrumentation. We could continue to expand America’s pre-eminent exploration of interstellar space until the middle of this century. And that lead will last unchallenged for a generation or more to come. But instead we are going to shut off this explorer – and many others – long before they cease to explore the unknown.

As NASA’s New Horizons spacecraft exits the Solar System bound for interstellar space, it has traveled so far that the nearest stars have shifted markedly from their positions seen from Earth.

We demonstrated this by imaging the Proxima Centauri and Wolf 359 fields from Earth and New Horizons on 2020 April 23, when the spacecraft was 47.1 au distant. The observed parallaxes for Proxima Centauri and Wolf 359 are 32.4″ and 15.7″, respectively.

These measurements are not of research grade, but directly seeing large stellar parallaxes between two widely separated simultaneous observers is vividly educational. Using the New Horizons positions of the two stars alone, referenced to the three-dimensional model of the solar neighborhood constructed from Gaia DR3 astrometry, further provides the spacecraft spatial position relative to nearby stars with 0.44 au accuracy.

The range to New Horizons from the Solar System barycenter is recovered to 0.27 au accuracy, and its angular direction to 0.4^∘ accuracy, when compared to the precise values from NASA Deep Space Network tracking. This is the first time optical stellar astrometry has been used to determine the three-dimensional location of a spacecraft with respect to nearby stars, and the first time any method of interstellar navigation has been demonstrated for a spacecraft on an interstellar trajectory.

We conclude that the best astrometric approach to navigating spacecraft on their departures to interstellar space is to use a single pair of the closest stars as references, rather than a large sample of more distant stars.

The location of New Horizons on 2020 April 23 as derived from the directions to Proxima Cen and Wolf 359 measured from the spacecraft. The view is from the ecliptic north pole; the vertical axis is at zero RA. Gray circles show the orbits of the outer planets. Line of position P passes through the Gaia 3-D location of Proxima Cen, in the direction measured from the spacecraft; the observations of Proxima Cen thus constrain the spacecraft to lie on line P. Similarly, observations of Wolf 359 constrain the spacecraft to lie on line of position W. The faint dotted lines show how much P and W would be displaced by a 1 ′′ change in line direction; the transverse displacement in au is just the distance to the star in pc (1.30 for P, 2.41 for W). The trajectory NH is the actual path of the spacecraft from launch in 2006 through 2023, marked with yearly tickmarks. The actual angular uncertainties are much less than the 1′′ indicated by the dotted lines. Line P is inclined ∼ 45^◦ from the ecliptic plane; line W and the NH trajectory are inclined less than 2^◦ from the ecliptic. — — astro-ph.IM

The Earth-based and New Horizons images of Proxima Centauri and its star field are shown side by side to demonstrate the large Earth-spacecraft parallax. Proxima Cen is the bright star near the center of the field. The field shown is 10′ × 10′ . North is at the top. The image pairs have been prepared to a common image scale, field, and orientation so that the parallax can also be recognized with stereo imaging. The top pair is positioned for “cross-eyed” viewing. Crossing your eyes to view the NH-based image with the left eye, and the Earth-based image with the right eye, will create the appearance of Proxima Cen floating in front of the background stars. The two images are swapped in position in the bottom row to allow for parallel viewing. In this case, the left eye views the left panel, and the right eye the right panel. Parallel viewing can also be done by mounting the images in a stereoscopic viewer. Our experience on the New Horizons team is that there is no clear preference between cross-eyed vs. parallel viewing. — astro-ph.IM

Tod R. Lauer, David H. Munro, John R. Spencer, Marc W. Buie, Edward L. Gomez, Gregory S. Hennessy, Todd J. Henry, George H. Kaplan, John F. Kielkopf, Brian H. May, Joel W. Parker, Simon B. Porter, Eliot Halley Vrijmoet, Harold A. Weaver, Pontus Brandt, Kelsi N. Singer, S. Alan Stern, Anne. J. Verbiscer, Pedro Acosta, Nicolás Ariel Arias, Sergio Babino, Gustavo Enrique Ballan, Víctor Ángel Buso, Steven J. Conard, Daniel Das Airas, Giorgio Di Scala, César Fornari, Jossiel Fraire, Brian Nicolás Gerard, Federico González, Gerardo Goytea, Emilio Mora Guzmán, William Hanna, William C. Keel, Aldo Kleiman, Anselmo López, Jorge Gerardo Machuca, Leonardo Málaga, Claudio Martínez, Denis Martinez, Raúl Meliá, Marcelo Monópoli, Marc A. Murison, Leandro Emiliano Fernandez Pohle, Mariano Ribas, José Luis Ramón Sánchez, Sergio Scauso, Dirk Terrell, Thomas Traub, Pedro Oscar Valenti, Ángel Valenzuela, Ted von Hippel, Wen Ping Chen, Dennis Zambelis

Comments: Accepted for publication in the Astronomical Journal. The introduction includes a link to the Jupyter notebook and images used in the analysis
Subjects: Instrumentation and Methods for Astrophysics (astro-ph.IM)
Cite as: arXiv:2506.21666 [astro-ph.IM] (or arXiv:2506.21666v1 [astro-ph.IM] for this version)
https://doi.org/10.48550/arXiv.2506.21666
Focus to learn more
Submission history
From: Tod R. Lauer
[v1] Thu, 26 Jun 2025 18:00:02 UTC (4,720 KB)
https://arxiv.org/abs/2506.21666

Astrobiology, Interstellar, Stellar Cartography,

A unique new material that shrinks when it is heated and expands when it is cooled could help enable the ultra-stable space telescopes that future NASA missions require to search for habitable worlds.

One of the goals of NASA’s Astrophysics Division is to determine whether we are alone in the universe. NASA’s astrophysics missions seek to answer this question by identifying planets beyond our solar system (exoplanets) that could support life. Over the last two decades, scientists have developed ways to detect atmospheres on exoplanets by closely observing stars through advanced telescopes. As light passes through a planet’s atmosphere or is reflected or emitted from a planet’s surface, telescopes can measure the intensity and spectra (i.e., “color”) of the light, and can detect various shifts in the light caused by gases in the planetary atmosphere. By analyzing these patterns, scientists can determine the types of gasses in the exoplanet’s atmosphere.

Decoding these shifts is no easy task because the exoplanets appear very near their host stars when we observe them, and the starlight is one billion times brighter than the light from an Earth-size exoplanet. To successfully detect habitable exoplanets, NASA’s future Habitable Worlds Observatory will need a contrast ratio of one to one billion (1:1,000,000,000).

Achieving this extreme contrast ratio will require a telescope that is 1,000 times more stable than state-of-the-art space-based observatories like NASA’s James Webb Space Telescope and its forthcoming Nancy Grace Roman Space Telescope. New sensors, system architectures, and materials must be integrated and work in concert for future mission success. A team from the company ALLVAR is collaborating with NASA’s Marshall Space Flight Center and NASA’s Jet Propulsion Laboratory to demonstrate how integration of a new material with unique negative thermal expansion characteristics can help enable ultra-stable telescope structures.

Material stability has always been a limiting factor for observing celestial phenomena. For decades, scientists and engineers have been working to overcome challenges such as micro-creep, thermal expansion, and moisture expansion that detrimentally affect telescope stability. The materials currently used for telescope mirrors and struts have drastically improved the dimensional stability of the great observatories like Webb and Roman, but as indicated in the Decadal Survey on Astronomy and Astrophysics 2020 developed by the National Academies of Sciences, Engineering, and Medicine, they still fall short of the 10 picometer level stability over several hours that will be required for the Habitable Worlds Observatory. For perspective, 10 picometers is roughly 1/10^th the diameter of an atom.

_{NASA’s Nancy Grace Roman Space Telescope sits atop the support structure and instrument payloads. The long black struts holding the telescope’s secondary mirror will contribute roughly 30% of the wave front error while the larger support structure underneath the primary mirror will contribute another 30%.}

_{Credit: NASA/Chris Gunn}

Funding from NASA and other sources has enabled this material to transition from the laboratory to the commercial scale. ALLVAR received NASA Small Business Innovative Research (SBIR) funding to scale and integrate a new alloy material into telescope structure demonstrations for potential use on future NASA missions like the Habitable Worlds Observatory. This alloy shrinks when heated and expands when cooled-a property known as negative thermal expansion (NTE). For example, ALLVAR Alloy 30 exhibits a -30 ppm/°C coefficient of thermal expansion (CTE) at room temperature. This means that a 1-meter long piece of this NTE alloy will shrink 0.003 mm for every 1 °C increase in temperature. For comparison, aluminum expands at +23 ppm/°C.

_{While other materials expand while heated and contract when cooled, ALLVAR Alloy 30 exhibits a negative thermal expansion, which can compensate for the thermal expansion mismatch of other materials. The thermal strain versus temperature is shown for 6061 Aluminum, A286 Stainless Steel, Titanium 6Al-4V, Invar 36, and ALLVAR Alloy 30.}

Because it shrinks when other materials expand, ALLVAR Alloy 30 can be used to strategically compensate for the expansion and contraction of other materials. The alloy’s unique NTE property and lack of moisture expansion could enable optic designers to address the stability needs of future telescope structures. Calculations have indicated that integrating ALLVAR Alloy 30 into certain telescope designs could improve thermal stability up to 200 times compared to only using traditional materials like aluminum, titanium, Carbon Fiber Reinforced Polymers (CFRPs), and the nickel-iron alloy, Invar.

To demonstrate that negative thermal expansion alloys can enable ultra-stable structures, the ALLVAR team developed a hexapod structure to separate two mirrors made of a commercially available glass ceramic material with ultra-low thermal expansion properties. Invar was bonded to the mirrors and flexures made of Ti6Al4V-a titanium alloy commonly used in aerospace applications-were attached to the Invar. To compensate for the positive CTEs of the Invar and Ti6Al4V components, an NTE ALLVAR Alloy 30 tube was used between the Ti6Al4V flexures to create the struts separating the two mirrors. The natural positive thermal expansion of the Invar and Ti6Al4V components is offset by the negative thermal expansion of the NTE alloy struts, resulting in a structure with an effective zero thermal expansion.

The stability of the structure was evaluated at the University of Florida Institute for High Energy Physics and Astrophysics. The hexapod structure exhibited stability well below the 100 pm/√Hz target and achieved 11 pm/√Hz. This first iteration is close to the 10 pm stability required for the future Habitable Worlds Observatory. A paper and presentation made at the August 2021 Society of Photo-Optical Instrumentation Engineers conference provides details about this analysis.

Furthermore, a series of tests run by NASA Marshall showed that the ultra-stable struts were able to achieve a near-zero thermal expansion that matched the mirrors in the above analysis. This result translates into less than a 5 nm root mean square (rms) change in the mirror’s shape across a 28K temperature change.

Beyond ultra-stable structures, the NTE alloy technology has enabled enhanced passive thermal switch performance and has been used to remove the detrimental effects of temperature changes on bolted joints and infrared optics. These applications could impact technologies used in other NASA missions. For example, these new alloys have been integrated into the cryogenic sub-assembly of Roman’s coronagraph technology demonstration. The addition of NTE washers enabled the use of pyrolytic graphite thermal straps for more efficient heat transfer. ALLVAR Alloy 30 is also being used in a high-performance passive thermal switch incorporated into the UC Berkeley Space Science Laboratory’s Lunar Surface Electromagnetics Experiment-Night (LuSEE Night) project aboard Firefly Aerospace’s Blue Ghost Mission 2, which will be delivered to the Moon through NASA’s CLPS (Commercial Lunar Payload Services) initiative. The NTE alloys enabled smaller thermal switch size and greater on-off heat conduction ratios for LuSEE Night.

Through another recent NASA SBIR effort, the ALLVAR team worked with NASA’s Jet Propulsion Laboratory to develop detailed datasets of ALLVAR Alloy 30 material properties. These large datasets include statistically significant material properties such as strength, elastic modulus, fatigue, and thermal conductivity. The team also collected information about less common properties like micro-creep and micro-yield. With these properties characterized, ALLVAR Alloy 30 has cleared a major hurdle towards space-material qualification.

As a spinoff of this NASA-funded work, the team is developing a new alloy with tunable thermal expansion properties that can match other materials or even achieve zero CTE. Thermal expansion mismatch causes dimensional stability and force-load issues that can impact fields such as nuclear engineering, quantum computing, aerospace and defense, optics, fundamental physics, and medical imaging. The potential uses for this new material will likely extend far beyond astronomy. For example, ALLVAR developed washers and spacers, are now commercially available to maintain consistent preloads across extreme temperature ranges in both space and terrestrial environments. These washers and spacers excel at counteracting the thermal expansion and contraction of other materials, ensuring stability for demanding applications.

For additional details, see the entry for this project on NASA TechPort.

Project Lead: Dr. James A. Monroe, ALLVAR

The following NASA organizations sponsored this effort: NASA Astrophysics Division, NASA SBIR Program funded by the Space Technology Mission Directorate (STMD).
